15″ right MOTOR REPLACEMENT BLOWER
FW1911
Previous
Next
Sealed ball bearing replacement blower. Blower includes Velcro, double-side tape and noise reduction padding. Power cord and blower support brace are NOT included. If you’re installing a blower for the first time, a blower kit may be required. Replacement blowers are intended to replace worn or defective blowers and do not include the components of a full blower kit.
160CFM
15″ x 4″ x 3.5″
Air discharge length 12.5″
Power cord not included
LENGTH X WIDTH X HEIGHT (W/O BRACKET): 15.0″ X 4.0″ X 3.5″
AIR DISCHARGE LENGTH: 12.5″
MOTOR TYPE: AC SHADED POLE
ROTATION: CW
MOTOR BEARING TYPE: BALL
OUTBOARD BEARING TYPE: BALL
HIGH TEMP LUBRICATION: YES
INSULATION: CLASS H (RATED TO 392°F)
MOTOR RPM: 3000
AIRFLOW IN C.F.M: 160
MOUNTING: MOUNTS USING SUPPLIED VELCRO AND TAPE
VOLTS: 120
FREQUENCY: 60 HZ
POWER CONSUMPTION: 52 WATTS
POWER CORD: NOT INCLUDED
RHEOSTAT VARIABLE SPEED: NOT INCLUDED
THERMOSTAT: NOT INCLUDED
BLADE MATERIAL: ALUMINUM
FRAME MATERIAL: ALUMINUM
PACKAGING MATERIALS: SHIPPING BOX, BUBBLE WRAP, FOAM
MAJESTIC
33ISD SERIES, 36CFDV SERIES, DVB DVB7 SERIES (300DVB, 400DVB, 500DVB, 600DVB), DVBH DVBH7 SERIES (300DVBH, 400DVBH), PFDV SERIES, VF VFR SERIES (VF32, VF36, VF42, VFR32, VFR36, VFR42), VFH SERIES (32VFH, 36VFH, 42VFH), VFS SERIES (32VFS)
MARTIN HEARTH AND HEATING
CDV SERIES (CDVR33, CDVR36, CDVR42, CDVR47, CDVT33, CDVT36, CDVT42, CDVT47), CDV7 CDVSC7 SERIES (CDVR33, CDVR36, CDVR42, CDVR47, CDVT33, CDVT36, CDVT42, CDVT47), DVB SERIES (300DVB, 400DVB, 500DVB, 600DVB), VHF SERIES (32VFH, 36VFH, 42VFH), GLCF36, GSTF36, GPF36, GRCF36, CLDV CRDV DESIGNER SERIES, GL SERIES (GLCF36, GPF36, GRCF36, GSTF36), PFDVD STDVD DESIGNER SERIES
MONESSEN
2000 SERIES (216DV3732, 216DV4136, 216DV4742), 3000 SERIES (320DV4136, 320DV4742), 624DV SEE-THRU DESIGNER, BDV BDV7 SERIES (300BDV, 400BDV, 500BDV, 600BDV), CDV CDV7 SERIES (CDVR33, CDVR36, CDVR42, CDVR47, CDVT33, CDVT36, CDVT42, CDVT47), CLDV CRDV DESIGNER SERIES, CHESAPEAKE (CFX24, CFX32), DBX24, DFX SERIES (DFX24, 24DFX, DFX32, 32DFX), DFS SERIES (DFS32, DFS36, DFS42), DIS33, DZ36, GDVR36, GDVR42, GDVT36, GDVT42, GCUF36, GCUF42, GRUF36, GRUF42, GSTF36 SEE-THRU, GPF36 PENINSULA, GRCF36, GLCF36, HBDV HBDV7 SERIES (HBDV300, HBDV400), IDV SERIES (IDV380, IDV490), MAGNUM UNVENTED (MCUF36D, MCUF42D)
VERMONT CASTINGS
36CFDV SERIES, DVB SERIES (300DVB, 400DVB, 500DVB)
-
WARNING: WHEN DEALING WITH ELECTRICITY, TAKE ALL NECESSARY PRECAUTIONS TO AVOID BEING SHOCKED.
PROP 65 WARNING: CANCER.HTTPS://WWW.P65WARNINGS.CA.GOV/
